Rp 1/2" 2-Way Pneumatic Brass Ball Valve - Double Acting
Reference:
V3M3C
Brand:
TamesonPRO
Mfr. Part:
1141-012 | PR32D
Rp 1/2" BSP female 2-way pneumatic brass ball valve, double acting. PTFE ball seal and stem seal - suitable for water, compressed air, oils, fuels, solvents, alcohols, lubricants, and gas. Rated to 40 bar at 20 °C, media temperature -20 to 130 °C (-4 to 266 °F).
- Regular price
- $184.79 USD
excl VAT
We sell only to registered businesses
Description
Specifications
Downloads
Related products
Description
This Rp 1/2" BSP female 2-way double acting pneumatic brass ball valve requires air pressure on both ports to open and close. It holds its last position on loss of air pressure.
The actuator operates across an ambient temperature range of -20 to 80 °C, suited for outdoor and industrial environments. No manual override is fitted - the valve cannot be operated without an air supply.
PTFE ball seal and stem seal make it suitable for water, compressed air, oils, fuels, solvents, alcohols, lubricants, and gas. Avoid use with strong acids, ammonia, or seawater. Rated to 40 bar at 20 °C, media temperature range -20 to 130 °C (-4 to 266 °F).
Pros:
- PTFE ball seal and stem seal - suitable for wide range of media.
- Ambient temperature -20 to 80 °C - suited for outdoor and industrial environments.
Cons:
- Brass not suitable for strong acids, ammonia, or seawater - check stainless steel variants.
- No manual override - valve cannot be operated without air supply.
- No defined fail-safe position - valve holds last position on air loss.
