Omron PHOTO ELECTRIC SensorS Light Sensor Energetic - E3FADP22OMI

Omron PHOTO ELECTRIC SensorS Light Sensor Energetic - E3FADP22OMI
Omron PHOTO ELECTRIC SensorS Light Sensor Energetic - E3FADP22OMI
Image may vary slightly
See specifications for accurate information.
Reference: E2SHU
Brand: Omron
Mfr. Part: E3FA2037H

Omron PHOTO ELECTRIC SENSORS E3FA / E3RA light sensor energetic, design electrical connection connector M12, housing form cylindrical. Threaded, 1 semiconductor outputs with, AWG number 23, operating agent safety class safety class 0, degree of protection (IP) IP67.

View all
$97.63
excl VAT
In stock +3 days On request On request
0 are currently in your cart. For orders exceeding 0, expect an increased lead time of 3 days. Up to 10 items available for online order. For higher quantities, please contact us on support@tameson.com to request the lead time. The item is not available for online order, please contact us on support@tameson.com to request the lead time.
Shipping to United States: $14.95
Free for orders > $390.00
Expected delivery in 5 - 6 business days

Customers rate us: 4.98 / 5

509 reviews at TrustedShops

Description
Specifications
Downloads

Description

Omron PHOTO ELECTRIC SENSORS E3FA / E3RA light sensor energetic, design electrical connection connector M12, housing form cylindrical. Threaded, 1 semiconductor outputs with, AWG number 23, operating agent safety class safety class 0, degree of protection (IP) IP67.

Downloads

Product datasheet (EN)
pdf
Download

Specifications

Operating distance (mm)
5 mm to 300 mm
Signal output
Type of switching output.
PNP
Pre failure notice
No
Electrical connection
Type of electric connection.
Connector M12
With time function
No
Material
Choose a housing material that is not corroded by the media and environment, and can withstand the temperatures and pressures. Check out our chemical resistance chart.
Plastic
Max. switching distance (mm)
300
Max. output current (mA)
100
With reflector
No
Rated control supply voltage Us at DC (V)
10 V to 30 V
Analogue output 0 V ... 10 V
No
Analogue output 0 mA ... 20 mA
No
Max. current (mA)
The maximum current output of the protected output channel.
100
Analogue output 4 mA ... 20 mA
No
Analogue output -10 V ... +10 V
No
With other analogue output
No
Setting procedure
Manual adjustment
With communication interface analogue
No
With communication interface AS-Interface
No
With communication interface CANOpen
No
With communication interface DeviceNet
No
With communication interface Ethernet
No
With communication interface INTERBUS
No
With communication interface PROFIBUS
No
With communication interface RS-232
No
With communication interface RS-422
No
With communication interface RS-485
No
With communication interface SSD
No
With communication interface SSI
No
Degree of protection (IP)
The Ingress Protection (IP) rating indicating the product's resistance to dust and water, crucial for outdoor or harsh conditions.
IP67
Type of switch function
Programmable/configurable
Operation agent-safety class
Safety class 0
Sensing mode
Light-/dark switching
Material of optical surface
Plastic
Response time (ms)
0.5
Switching frequency (Hz)
2000
Type of safety according to IEC 61496-1
1
Laser protection class
None
Wavelength of the sensor (nm)
624
Type of light
Polarity free red light
Light dot (mm²)
2000
AWG-number
23
Material of cable sheath
Other
With restart blockage
No
Suitable for safety functions
No
Voltage-type
DC
Diameter sensor (mm)
18
Degree of protection (NEMA)
Other
Ambient temperature (°C)
-25 °C to 55 °C
Width sensor (mm)
15
Length of sensor (mm)
45
Height of sensor (mm)
18
