Hydrogen, Methane, Natural Gas And Coal Gas (fuel Gas) 300 bar Bottle Regulator With 0 to 10 bar Pressure Setting Range
Notice: This product is discontinued, a possible alternative is M27Z9
Brass bottle pressure regulator suitable for hydrogen, methane, natural gas and coal gas (fuel gas) applications up to a maximum inlet pressure of 300 bar. It is designed to mount directly on a W 30 x 2 LH (Ø 15.2/20.8) bottle with a female threaded port. It has a 9 mm hose barb to connect a hose. The outlet pressure needs to be manually set between 0 to 10 bar. Two mounted pressure gauges indicate the inlet and working pressure. The regulator is equipped with a shut-off valve for on/off control. In addition to that, it is made in accordance to DIN EN ISO 2503, which is related to gas welding equipment.
Notice: This product is discontinued, a possible alternative is M27Z9
Description
This is a brass bottle pressure regulator for hydrogen, methane, natural gas and coal gas (fuel gas) at a maximum pressure of 300 bar. It lowers the inlet pressure to a preset value, ranging from 0 to 10 bar. Connect the W 30 x 2 LH (Ø 15.2/20.8) female threaded port with a supply bottle and a 9 mm hose barb with a suitable hose. To set the pressure, screw the rod, on the lower side of the body, in or out. The pressure gauge on the inlet port indicates the inlet pressure and the pressure gauge on the outlet port indicates the preset or working pressure. The regulator is designed in accordance with DIN EN ISO 2503 and the bottle connection port conforms to DIN 477-5 standard.
Pros:
- Mounted with two pressure gauges for both inlet and outlet pressure
- Equipped with a shut off valve for on/off control
- Designed in accordance with DIN EN ISO 2503 for welding applications
- The bottle connection conforms to DIN 477-5 standard
- Replaceable hose connection
PRLB series
Bottle pressure regulator series consists of devices used for gas welding purposes designed in accordance with DIN EN ISO 2503. The regulators are suitable for different gases, like air, nitrogen, argon, helium, CO2. They can be used for maximum inlet pressures of up 300 bar and set the working pressure within the ranges of 0-10, 0-20 or 0-100 bar. Depending on the design these regulators can be equipped with either two pressure gauges or with a pressure gauge and flow meter combination. Some pressure regulators are equipped with a shut-off valve that provides on/off control.
