Cylinder Pressure Regulator Fuel Gas 300 bar to 0-20 bar W30x2 (15.2/20.8) Female
This brass cylinder pressure regulator is suitable for hydrogen, methane, natural gas and coal gas (fuel gas) at a maximum pressure of 300 bar. It lowers the inlet pressure to an adjustable range of 0-20 bar. The W 30 x 2 LH (Ø 15.2/20.8) female threaded port connects to the supply bottle (conforming DIN 477-5). The G 3/8 inch LH male threaded port connects to a suitable hose. Use the handwheel located on the bottom to adjust the outlet pressure. The pressure gauges are well protected by the robust rubber enclosure and clearly display the inlet and outlet pressure in three different scales. The regulator is designed in accordance with DIN EN ISO 2503 and the bottle connection port conforms to DIN 477-5 standard.
- Regular price
- $291.56 USD
Description
This brass cylinder pressure regulator is suitable for hydrogen, methane, natural gas and coal gas (fuel gas) at a maximum pressure of 300 bar. It lowers the inlet pressure to an adjustable range of 0-20 bar. The W 30 x 2 LH (Ø 15.2/20.8) female threaded port connects to the supply bottle (conforming DIN 477-5). The G 3/8 inch LH male threaded port connects to a suitable hose. Use the handwheel located on the bottom to adjust the outlet pressure. The pressure gauges are well protected by the robust rubber enclosure and clearly display the inlet and outlet pressure in three different scales. The regulator is designed in accordance with DIN EN ISO 2503 and the bottle connection port conforms to DIN 477-5 standard.
Pros:
- Regulates fuel gasses up to 300 bar to a 0-20 bar pressure
- Inlet and outlet pressure gauge with rugged rubber cover
- Shut-off valve to stop the gas flow
- Safe design meeting DIN EN ISO 2503
- W 30 x 2 LH (Ø 15.2/20.8) female threaded bottle connection conforms to DIN 477-5 standard (not CGA)
