G 1/2 inch Brass 2-Way Boiler Filling and Draining Ball Valve
Boiler filling and draining ball valve with a male G 1/2 inch inlet port and a 13 mm hose barb as outlet port. The valve bore is 10 mm and the maximum pressure is 10 bar or 145 psi. Suitable for water (no steam), neutral, non-aggressive and non-toxic liquid media. Suitable for temperatures from -10 to 90 °C (14 to 194 °F). Nickel-plated brass housing, hard chrome plated brass ball and PTFE/NBR sealings.
- Regular price
- $12.98 USD
We sell only to registered businesses
Description
This 2-way brass ball valve with a nominal diameter of 10 mm is designed for boiler filling and draining.
The valve has a male G 1/2 inch inlet port and a 13 mm hose barb outlet port. The hose barb is removable.
The housing of the valve is made of nickel-plated brass, the ball is made of hard chrome plated brass and the sealings are made of PTFE/NBR. Suitable for water (no steam), neutral, non-aggressive and non-toxic liquid media up to a maximum pressure of 10 bar or 145 psi. The valve is suitable for temperatures from -10 to 90 °C (14 to 194 °F).
Use the rotary knob to operate the valve. By rotating it 90 degrees, the valve will open or close. If it is perpendicular to the pipe, the valve is closed.
Pros:
- Unobstructed flow of the media thanks to the full bore design
- Ideal as filling or draining valve for heating installations
- Including a closing cap to prevent accidental leaks
Cons:
- Not suitable for aggressive media
BL2BN-MBF series
View our 2-way brass ball valve BL2BN-MBF series designed for boiler filling and draining. The inlet port is 1/2 inch. The outlet port has a removable 13 mm hose barb. The housing material is nickel-plated brass, the ball material is hard chrome plated brass and the sealings are PTFE/NBR. The valve is suitable for a wide variety media, such as water (no steam), neutral, non-aggressive and non-toxic liquid media up to a maximum pressure of 10 bar or 145 psi. The valve can be used within a temperature range from -10 to 90 °C (14 to 194 °F). The series is handle operated and provides reliability and a long service life.
