This is an elbow SAE flange with a cutting ring connection port. It adheres to SAE Code 62 (6000 psi working pressure) and has an SAE-4 mounting pattern size of 1/2 inch. Connection 2 is a 16 mm cutting ring with an M24x1.5 union nut. It has a flange diameter of 31.7 mm. The body is made of zinc plated steel with an NBR seal. The maximum pressure is 400 bar (5800 psi) and the fitting is suitable for temperatures from -30 to 90 °C (-22 to 194 °F). It is made in accordance with the ISO 6162-2.
