8mm & G1/4'' Brass Swivel Joint Compression Fitting with Male Threads 135 bar Polyamide DIN EN 1254-2
Image may vary slightly
See specifications for accurate information.
Reference:
F2A24
Brand:
Tameson
This brass elbow swivel joint is designed with one male threaded connection and one compression ring connection port. Connection 1 is a 8 mm compressi
- Regular price
- $9.38 USD
excl VAT
Shipping to United States: Free
Shipping to United States: $14.95 USD
Free for orders > $390.00 USD
Expected delivery in 4 - 5 business days
We sell only to registered businesses
Description
Specifications
Description
This brass elbow swivel joint is designed with one male threaded connection and one compression ring connection port. Connection 1 is a 8 mm compression ring with a M12x1 union nut. Connection 2 has male G 1/4 inch threads. The seal material is Polyamide. The maximum pressure is 135 bar (1958 psi). The fitting is suitable for temperatures from -20 to 80 °C (-4 to 176 °F). It is made in accordance with DIN EN 1254-2.
Pros:
- Adheres to DIN EN 1254-2
- Suitable for neutral and non-corrosive media
Cons:
- The brass compression ring screw connections cannot be combined with the cutting ring pipe screw connectors ISO 8434-1 (DIN 2353)
