Reference: BW2-100
Brand: JP Fluid Control

1 inch 2/2 way brass ball valve with chrome plated ball and PTFE seal. Suitable for liquids and gases (from -10 to 110°C). Regularly used in heating systems. The valve is compatible with the AW1 actuator. The orifice has a diameter of 19 mm, the Kv-value is 21 m3/h (433.4 l/min at dP=1 bar, water).

View all
Regular price
$46.35 USD
excl VAT

In stock Ships in 0d On request On request
0 are currently in your cart. For orders exceeding 74, expect an increased lead time of 0 days. Up to 124 items available for online order. For higher quantities, please contact us on support@tameson.com to request the lead time. The item is not available for online order, please contact us on support@tameson.com to request the lead time.


Shipping to United States: $14.95 USD
Free for orders > $390.00 USD
Expected delivery in 2 - 3 business days

Description
Specifications
Downloads
Related products

This 2/2 way ball valve by JP Fluid Control is meant to be electrically operated (compatible with AW1 actuator). The valve has G1 inch inner port threads (BSPP) and is suitable for neutral liquids and gases (-10 up to 110°C). This type of valve is often used in heating systems. A ball valve is less sensitive to dirt than a solenoid valve. It is however recommended to install a filter before the valve. The valve body is made of brass, and features a chrome plated ball and a seal of PTFE (Teflon). The orifice has a diameter of 19 mm and the valve has a Kv-value of 21 m3/hr. This means that the flow is approximately 350 l/min at a differential pressure of 1 bar.

Important

  • Suitable for clean gases and liquids, including cold & hot water.
  • Make sure that the valve is suitable for the application and that the materials are suitable for the medium and the temperature

Note: this valve is not suited for dry gases such as unlubricated compressed air.

Assembly
