ABB CP-D DC Power Supply 24V | 1SVR427044R0200

ABB CP-D DC Power Supply 24V | 1SVR427044R0200
ABB CP-D DC Power Supply 24V | 1SVR427044R0200
Image may vary slightly
See specifications for accurate information.
Reference: E24JJ
Brand: ABB
Mfr. Part: 1SVR427044R0200

The CP-D 24-2.5 power supply is part of the CP-D series. The primary switch mode power supply has a wide input range of 90-264 VAC and 120-375V DC. Rated input voltage is between 100-240V AC. Rated output power is 60W, and rated current is 2.5A at an output voltage 24 VDC. The output voltage can be adjusted between 24 and 28 V DC. The power supply has a U/I output characteristic.

View all
$120.19
excl VAT
In stock +40 days On request On request
0 are currently in your cart. For orders exceeding 0, expect an increased lead time of 40 days. Up to 30 items available for online order. For higher quantities, please contact us on support@tameson.com to request the lead time. The item is not available for online order, please contact us on support@tameson.com to request the lead time.
Shipping to United States: $14.95
Free for orders > $390.00
Expected delivery in 42 - 43 business days

Customers rate us: 4.98 / 5

506 reviews at TrustedShops

Description
Specifications
Downloads
Related products

Description

The CP-D 24-2.5 power supply is part of the CP-D series. The primary switch mode power supply has a wide input range of 90-264 VAC and 120-375V DC. Rated input voltage is between 100-240V AC. Rated output power is 60W, and rated current is 2.5A at an output voltage 24 VDC. The output voltage can be adjusted between 24 and 28 V DC. The power supply has a U/I output characteristic.

Downloads

Datasheet (EN)
pdf
Download

Specifications

Voltage type of supply voltage
AC/DC
1st secondary output voltage at DC (V)
24 V to 24 V
Max. output current 1 (A)
2.5
Secondary voltage adjustable
No
Nominal value output voltage 1 (V)
24
Nominal value output current 1 (A)
2.5
Rated voltage AC (V)
90 V to 264 V
Rated voltage (AC 60 Hz) (V)
90 V to 264 V
Rated voltage DC (V)
120 V to 375 V
Electrical connection
Type of electric connection.
Screw connection
Output voltage stabilized
Yes
Power consumption (VA)
70.1
Power output (W)
60
Stabilized
Yes
Short-circuit-proof
Yes
Degree of protection (IP)
The Ingress Protection (IP) rating indicating the product's resistance to dust and water, crucial for outdoor or harsh conditions.
IP20
Suitable for safety functions
No
SIL (IEC 61508)
None
Refurbished
No
Modular version
Yes
Direct mounting possible
No
Wall mounting possible
No
Rail mounting possible
Yes
Performance level (EN ISO 13849-1)
None
Degree of protection (NEMA)
EV001823
Width in number of modular spacings
3
Built-in width (mm)
71
Built-in height (mm)
91
