6mm - 6mm PBT Union Straight Pressure Gauge
Notice: This product will be discontinued in the future
This is a union straight pressure gauge for pneumatic system pressure measurement. The scale is in MPa. It has 6 mm push-in fittings on both sides. It is suitable for a maximum operating pressure of 8 bar (116 psi). It has NBR seals that make it suitable for applications within a temperature range from 0 to 60 °C (32 to 140 °F).
Notice: This product will be discontinued in the future
Description
This is a union straight pressure gauge for pneumatic system pressure measurement. Connect the pressure gauge to your system and it will show the pressure rating in MPa.
It has 6 mm push-in fittings on both sides. The push-in fitting provides an easy connection with the tubing. Push the tube in and the fitting will fix it with stainless steel claws.
It is suitable for a maximum operating pressure of 8 bar (116 psi. It has NBR seals that make it suitable for applications within a temperature range from 0 to 60°C (32 to 140 °F) (no freezing).
Pros:
- Equipped with easy to connect push-in fittings
Cons:
- Not suitable for vacuum applications
GPU series
The GPU – series includes union straight pressure gauges for pneumatic system pressure measurement. They have two ports with push-in fittings. The sizes range from 4 mm to 8 mm. The indicated pressure range is from 0 to 8 bar. The pressure gauges are suitable for a temperature range from 0 to 60°C (no freezing). The scale is in MPa.
