Reference: E3XCB
Brand: EATON INDUSTRIES
Mfr. Part: 088916

IEC/EN60947-compliant transformer circuit breaker featuring 3-pole PKZM0 design with adjustable overload and non-delayed short-circuit protection. Includes phase failure sensitivity, 690V rated operating voltage, and IP20 protection rating. Features screw terminals and snap fitting with 45mm cap installation dimension. Compatible with auxiliary contact and voltage release accessories.

View all

Notice: This product will be discontinued in the future

Description
Specifications
Downloads

Description

IEC/EN60947-compliant transformer circuit breaker featuring 3-pole PKZM0 design with adjustable overload and non-delayed short-circuit protection. Includes phase failure sensitivity, 690V rated operating voltage, and IP20 protection rating. Features screw terminals and snap fitting with 45mm cap installation dimension. Compatible with auxiliary contact and voltage release accessories.

Pros:

  • Adjustable overload and short-circuit protection
  • Phase failure sensitivity for enhanced safety
  • High 690V operating voltage rating
  • Versatile mounting with screw and snap fitting options

Downloads

Installation and Maintenance (EN)
pdf
Download
Installation and Maintenance (EN)
pdf
Download
Installation and Maintenance (EN)
pdf
Download
Brochure (EN)
pdf
Download
Compliance and Certification (EN)
pdf
Download
Compliance and Certification (EN)
pdf
Download

Specifications

Rated permanent current Iu
10 A
Rated voltage
690..690 V
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz
150 kA
Overload release current setting
6.3..10 A
Adjustment range short-term delayed short-circuit release
0..0 A
Adjustment range undelayed short-circuit release
224..224 A
Integrated earth fault protection
No
Type of electrical connection of main circuit
Screw connection
Device construction
Built-in device fixed built-in technique
Suitable for DIN rail (top hat rail) mounting
Yes
DIN rail (top hat rail) mounting optional
Yes
Number of auxiliary contacts as normally closed contact
0
Number of auxiliary contacts as normally open contact
0
Number of auxiliary contacts as change-over contact
0
With switched-off indicator
Yes
With integrated under voltage release
No
Number of poles
3
Position of connection for main current circuit
Other
Type of control element
Turn button
Complete device with protection unit
No
