230 - G1-1/2'' 2-Way Ball Valve Full Bore F/F ISO-Top
Notice: This product is discontinued and replaced by BL2BA-112
2-Way ball valve with G1-1/2 inch threads (F/F) and ISO-Top (F04) and 40mm nominal diameter and max pressure 32 bar. For i.e. water, oil, air etc. Temperature range from -10 to 100°C. Nickel plated brass hard chromed ball and PTFE seals.
Notice: This product is discontinued and replaced by BL2BA-112
Description
2-Way ball valve of nickel plated brass from JP Fluid Control with G1-1/2 inch pipe threads (BSPP) and a full bore (40 mm). The valve has an ISO-Top flange and is not provided with a lever for manual control. The ball valves in the 230-series of JP Fluid Control are characterized by long life.
Technical Specifications
| Parameter | Value |
|---|---|
| Series | 230 |
| Function | 2-way |
| Ports | G1-1/2 BSP (F/F) |
| Housing | Nickel plated brass (CW 617N) |
| Ball | Hard chrome plated brass |
| Seals | PTFE (teflon) |
| Nominal Diameter | 40 mm (full bore) |
| Kv value | 170 m3/h |
| Operation | Suitable for automatic control (no manual lever) |
| ISO 5211 flange | F04 |
| Max pressure | 32 bar |
| Temperature | -10°C .. 100°C |
Installation
The valve has female thread on both sides (1-1/2 inch). This is BSPP (British Standard Pipe Parallel). With our range of
Maximum pressure versus temperature - 230-series.
