Zehnder ComfoAir Three-Position Switch - 659000150

Notice: This product is discontinued

Discontinued
Zehnder ComfoAir Three-Position Switch - 659000150
Zehnder ComfoAir Three-Position Switch - 659000150
Image may vary slightly
See specifications for accurate information.
Reference: E2ZCM
Brand: Zehnder
Mfr. Part: 659000150

Switch for adjusting the fan speed in 3 modes + 0 for DC fans such as CVF. By installing a SAG 0-3CV (formerly SA 0-3CVC) multiple DC fans can be connected together, to a maximum of 20 units. The casing is white, RAL 9010, and by default is suitable for flush installation in a socket box with 40 mm depth. A mounting box is available for surface mounting. Zehnder SAG 0-3 CV switch.

View all

Notice: This product is discontinued

Description
Specifications
Downloads

Description

Switch for adjusting the fan speed in 3 modes + 0 for DC fans such as CVF. By installing a SAG 0-3CV (formerly SA 0-3CVC) multiple DC fans can be connected together, to a maximum of 20 units. The casing is white, RAL 9010, and by default is suitable for flush installation in a socket box with 40 mm depth. A mounting box is available for surface mounting. Zehnder SAG 0-3 CV switch.

Downloads

Specifications

Assembly arrangement
Basic element with housing top
Method of operation
Turn button
Wiring system
Other
Mounting method
Flush mounted (plaster)
Material
Choose a housing material that is not corroded by the media and environment, and can withstand the temperatures and pressures. Check out our chemical resistance chart.
Plastic
Material quality
Choose a housing material that will not corrode from the media and environment, and can withstand the application's temperature and pressure.
Duroplast
Halogen free
Yes
Surface protection
The type of surface protection of the component.
Untreated
Surface finishing
Glossy
Color
White
RAL-number (similar)
9010
Transparent
No
Rated current (A)
0.001
Nominal voltage (V)
12
Type of fastening
Mounting with screw
Min. depth of built-in installation box (mm)
31.7
