Rp 1-1/4 inch 2-Way Oxygen Brass Ball Valve
2-Way brass ball valve for oxygen with Rp 1-1/4 inch ports and a handle for on/off flow control. 32 mm nominal diameter and a maximum pressure of 10 bar (145 psi). The valve is suitable for oxygen (industrial) and argon. The valve can be used within a temperature range from -10 to 60 °C (14 to 140 °F). Nickel-plated brass housing, brass ball and PTFE/FKM seals.
- Regular price
- $114.11 USD
We sell only to registered businesses
Description
This 2-way ball valve from Tameson with a nominal diameter of 32 mm is designed for on/off flow control.
The valve has Rp 1-1/4 inch threaded ports. This is BSPT (British Standard Pipe Taper). With our range of 1-1/4 inch fittings, the valve can be installed in any pipe.
The housing of the valve is made of nickel-plated brass, the ball is made of brass and the seals are made of PTFE/FKM. The valve is suitable for oxygen (industrial) and argon up to a maximum pressure of 10 bar (145 psi). The valve can be used within a temperature range from -10 to 60 °C (14 to 140 °F).
Use the handle to operate the valve. By rotating it 90 degrees, the valve will open or close. If the handle is perpendicular to the pipe, the valve is closed. This valve is not suitable for electrical or pneumatic control. For this purpose, valves with an ISO-Top flange (ISO 5211) are recommended.This valve is not suitable for electrical or pneumatic control. For this purpose, valves with an ISO-Top flange (ISO 5211) are recommended.
Pros:
- Suitable for oxygen (industrial)
Cons:
- Not suitable for aggressive media
- Suitable only for manual actuation
BL2BN-M-O2 series
The BL2BN-M-O2 series includes brass ball valves designed for oxygen (industrial) and argon appliances. The valves are equipped with female threaded ports from 1/4 to 2 inch. The ports conform to BSPT (British Standard Pipe Taper). The housing is made of nickel-plated brass and the seals are PTFE/FKM. The valves are suitable for oxygen (industrial) and argon up to a maximum pressure of 50 bar (725 psi). This series is handle operated within the temperature range from -10 to 60 °C (14 to 140 °F).
