Image may vary slightly
See specifications for accurate information.
Reference: E2Z2X
Brand: Phoenix Contact
Mfr. Part: 2908262

1-channel, electronic circuit breaker for protecting loads at 24 V DC against overload and short circuit. Easy potential distribution with components from the CLIPLINE complete terminal block system. With electronic interlock of the set nominal currents. For installation on DIN rails.

View all
$46.91 USD
excl VAT
In stock Ships in 3d On request On request
0 are currently in your cart. For orders exceeding 0, expect an increased lead time of 3 days. Up to 37 items available for online order. For higher quantities, please contact us on support@tameson.com to request the lead time. The item is not available for online order, please contact us on support@tameson.com to request the lead time.
Shipping to United States: $14.95 USD
Free for orders > $390.00 USD
Expected delivery in 5 - 6 business days

Customers rate us: 4.95 / 5

552 reviews at TrustedShops

Description
Specifications

Description

1-channel, electronic circuit breaker for protecting loads at 24 V DC against overload and short circuit. Easy potential distribution with components from the CLIPLINE complete terminal block system. With electronic interlock of the set nominal currents. For installation on DIN rails.

Specifications

Type of fuse insert
Mini circuit breaker
Type of fuse holder
Other
Type of indication element for defect indication
None
Supply voltage for defect-indication (V)
0 V to 30 V
Voltage type for defect indication
DC
Connectable conductor cross section fine-strand with cable end sleeve (mm²)
0.2 mm² to 2.5 mm²
Connectable conductor cross section solid-core (mm²)
0.2 mm² to 4 mm²
Rated current In (A)
24
Type of electrical connection 1
Other
Number of levels
2
Material insulation body
Other
Inflammability class of insulation material according to with UL94
Other
Closing plate required
No
