Reference: E2Z2V
Brand: Phoenix Contact
Mfr. Part: 2907919

Type 2/3 surge protection, consisting of protective plug and base element with screw connection. For single-phase power supply network with integrated status indicator and remote signaling. Nominal voltage = 230 V AC/DC.

View all
$126.25 USD
excl VAT
In stock Ships in 2d On request On request
0 are currently in your cart. For orders exceeding 0, expect an increased lead time of 2 days. Up to 2 items available for online order. For higher quantities, please contact us on support@tameson.com to request the lead time. The item is not available for online order, please contact us on support@tameson.com to request the lead time.
Shipping to United States: $14.95 USD
Free for orders > $390.00 USD
Expected delivery in 4 - 5 business days

We sell only to registered businesses

Customers rate us: 4.95 / 5

552 reviews at TrustedShops

Description
Specifications

Description

Type 2/3 surge protection, consisting of protective plug and base element with screw connection. For single-phase power supply network with integrated status indicator and remote signaling. Nominal voltage = 230 V AC/DC.

Specifications

Nominal voltage AC (V)
240
Max. continuous voltage AC (V)
264
Max. continuous voltage DC (V)
275
Nominal load current (A)
26
Nominal discharge surge current (8/20) (L-N) (kA)
5
Total discharge current (8/20) (L+N-PE) (kA)
5
Voltage protection level (kV)
1.25
Voltage protection level L-N (kV)
1.25
Voltage protection level L-PE/N-PE (kV)
1.4
Number of poles
2
Mounting method
Other
Max. conductor cross section solid (solid, stranded) (mm²)
4
Max. conductor cross section flexible (fine-strand) (mm²)
2.5
With remote signalling contact
Yes
Signalling at the device
Optic
Category type 3
Yes
With interference suppressor filter
No
