Operating distance (mm)
0 mm to 700 mm
Max. switching distance (mm)
700
Max. output current (mA)
3000
Rated control supply voltage Us at AC 50HZ (V)
24 V to 240 V
Rated control supply voltage Us at AC 60HZ (V)
24 V to 240 V
Rated control supply voltage Us at DC (V)
12 V to 240 V
Analogue output 0 V ... 10 V
No
Analogue output 0 mA ... 20 mA
No
Analogue output 4 mA ... 20 mA
No
Analogue output -10 V ... +10 V
No
With other analogue output
No
Setting procedure
Manual adjustment
With communication interface analogue
No
With communication interface AS-Interface
No
With communication interface CANOpen
No
With communication interface DeviceNet
No
With communication interface Ethernet
No
With communication interface INTERBUS
No
With communication interface PROFIBUS
No
With communication interface RS-232
No
With communication interface RS-422
No
With communication interface RS-485
No
With communication interface SSD
No
With communication interface SSI
No
Degree of protection (IP)
IP66
Type of switch function
Change-over contact (NO/NC)
Operation agent-safety class
Safety class 0
Sensing mode
Light-/dark switching
Material of optical surface
Plastic
Switching frequency (Hz)
16
Type of safety according to IEC 61496-1
1
Laser protection class
None
Wavelength of the sensor (nm)
950
Type of light
Infrared light
Material of cable sheath
Other
Suitable for safety functions
No
Degree of protection (NEMA)
Other
Ambient temperature (°C)
-25 °C to 55 °C
