Niko Conventional Transformer Low-Voltage Lighting System - 320-00003

Niko Conventional Transformer Low-Voltage Lighting System - 320-00003
Niko Conventional Transformer Low-Voltage Lighting System - 320-00003
Image may vary slightly
See specifications for accurate information.
Reference: E3AR4
Brand: Niko
Mfr. Part: 320-00003

This wound transformer from Niko has an output of 35W and is suitable for connecting low voltage lamps (12 V LED). These lamps can then be dimmed with phase-cut and universal dimmers. The transformer has two screw terminals on the primary side and four on the secondary side for connecting the mechanism. Matching mounting feet are included. Transformers from Niko are available in several variants.

View all
Note: product cannot be returned
$79.26
excl VAT
In stock +40 days On request On request
0 are currently in your cart. For orders exceeding 0, expect an increased lead time of 40 days. Up to 52 items available for online order. For higher quantities, please contact us on support@tameson.com to request the lead time. The item is not available for online order, please contact us on support@tameson.com to request the lead time.
Shipping to United States: $14.95
Free for orders > $390.00
Expected delivery in 42 - 43 business days

Customers rate us: 4.98 / 5

506 reviews at TrustedShops

Description
Specifications
Downloads

Description

This wound transformer from Niko has an output of 35W and is suitable for connecting low voltage lamps (12 V LED). These lamps can then be dimmed with phase-cut and universal dimmers. The transformer has two screw terminals on the primary side and four on the secondary side for connecting the mechanism. Matching mounting feet are included. Transformers from Niko are available in several variants.

Downloads

pdf
Download
Compliance and Certification (EN)
pdf
Download
Product datasheet (EN)
pdf
Download
Product datasheet (EN)
pdf
Download

Specifications

Type of transformer
Iron core transformer
Safety transformer
No
Output voltage (V)
11.6 V to 11.6 V
Power (W)
105 W to 105 W
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
No
Dimming manufacturer's proprietary system
No
Dimming mains voltage modulation
No
Dimming phase cut-off
No
Dimming phase cut-on
Yes
Dimming programmable
No
Dimming with push-button
Yes
Connection type primary side
Screw connection
Connection type secondary side
Screw connection
Surface-mounted
Yes
Built-in
No
Material
Choose a housing material that is not corroded by the media and environment, and can withstand the temperatures and pressures. Check out our chemical resistance chart.
Plastic
Color
Black
Short-circuit protected
Yes
Overload protection
Yes
Overtemperature protection
Yes
Number of output positions (pairs)
2
Degree of protection (IP)
The Ingress Protection (IP) rating indicating the product's resistance to dust and water, crucial for outdoor or harsh conditions.
IP20
