Reference: E3TX2
Brand: Finder
Mfr. Part: 22.32.0.230.4520

Compact 17.5mm modular contactor featuring 1NO+1NC configuration rated at 25A/250VAC. Equipped with 230 VAC/DC coil voltage and premium AgSnO2 contact material. Includes mechanical position indicator and LED status display for clear operational feedback.

View all
$29.52 USD
excl VAT
In stock Ships in 2d On request On request
0 are currently in your cart. For orders exceeding 0, expect an increased lead time of 2 days. Up to 34 items available for online order. For higher quantities, please contact us on support@tameson.com to request the lead time. The item is not available for online order, please contact us on support@tameson.com to request the lead time.
Shipping to United States: $14.95 USD
Free for orders > $390.00 USD
Expected delivery in 4 - 5 business days

We sell only to registered businesses

Customers rate us: 4.95 / 5

552 reviews at TrustedShops

Description
Specifications
Downloads

Description

Compact 17.5mm modular contactor featuring 1NO+1NC configuration rated at 25A/250VAC. Equipped with 230 VAC/DC coil voltage and premium AgSnO2 contact material. Includes mechanical position indicator and LED status display for clear operational feedback.

Pros:

  • Compact 17.5mm width saves panel space
  • Premium AgSnO2 contacts for enhanced durability
  • Dual position indicators (mechanical and LED)

Downloads

Compliance and Certification (EN)
pdf
Download
Installation and Maintenance (EN)
pdf
Download
Compliance and Certification (EN)
pdf
Download

Specifications

Rated operating voltage (V)
250 V to 440 V
Rated operation current (A)
25
Rated excitation voltage (V)
230 V to 230 V
Voltage type (operating voltage)
AC/DC
Voltage type (excitation voltage)
AC/DC
Number of contacts as normally open contact
1
Number of contacts as normally closed contact
1
Max. incandescent lamp load (W)
2000
Max. load fluorescent lamp (VA)
800
Max. load fluorescent lamp (Duo circuit) (VA)
500
Max. load fluorescent lamp (parallel compensated) (VA)
200
Slider for hand switch
No
Width in number of modular spacings
1
Built-in depth (mm)
60.8
Additional equipment possible
Yes
With day/night function
No
Hum-free
Yes
Degree of protection (IP)i
IP20
