Hirschmann Multimedia Coaxial Cable - 695004556 [500 Meters]

Hirschmann Multimedia Coaxial Cable - 695004556 [500 Meters]
Hirschmann Multimedia Coaxial Cable - 695004556 [500 Meters]
Image may vary slightly
See specifications for accurate information.
Reference: E2QM6
Brand: Hirschmann Multimedia
Mfr. Part: 695004556

Hirschmann Multimedi coaxial cable, cable type coax 9, sheath green, inner conductor class 1 = solid, CPR Euro fire class vlgs EN 13501-6 fca, shielding 2-fold, ground cable, sheath material polyethylene (PE), outer diameter 7mm, inner conductor diameter 1.05mm, processing in earth/substrate.

View all
$937.22
excl VAT
In stock +40 days On request On request
0 are currently in your cart. For orders exceeding 0, expect an increased lead time of 40 days. Up to 5 items available for online order. For higher quantities, please contact us on support@tameson.com to request the lead time. The item is not available for online order, please contact us on support@tameson.com to request the lead time.
Shipping to United States: Free
Free for orders > $390.00
Expected delivery in 42 - 43 business days

Customers rate us: 4.98 / 5

506 reviews at TrustedShops

Description
Specifications
Downloads

Description

Hirschmann Multimedi coaxial cable, cable type coax 9, sheath green, inner conductor class 1 = solid, CPR Euro fire class vlgs EN 13501-6 fca, shielding 2-fold, ground cable, sheath material polyethylene (PE), outer diameter 7mm, inner conductor diameter 1.05mm, processing in earth/substrate.

Downloads

Specifications

Diameter inner conductor (mm)
1.05
Inner conductor material
Copper
Inner conductor surface
Bare
Inner conductor category
Class 1 = solid
Diameter outer conductor (mm)
4.9
Outer conductor material
Copper
Outer conductor surface
Bare
Type of outer conductor
Foil + braiding
Dielectric
Solid PE (HD-PE)
Number of screen layers
2
Specification material outer sheath
Polyethylene (PE)
Colour outer sheath
Green
Reaction-to-fire class according to EN 13501-6
Fca
UV resistant
No
Characteristic impedance (Ohm)
75
Outer diameter approx. (mm)
7
Min. permitted bending radius, moving application with forced guidance (mm)
70
Min. permitted bending radius, moving application/free movement (mm)
140
Min. permitted bending radius, stationary application/permanent installation (mm)
70
Suitable for underground installation
Yes
Permitted cable outer temperature during assembling/handling (°C)
-5 °C to 50 °C
Permitted cable outer temperature after assembling without vibration (°C)
-5 °C to 50 °C
