Hager Quickbusbar Circuit Breaker - MCS616E

Hager Quickbusbar Circuit Breaker - MCS616E
Hager Quickbusbar Circuit Breaker - MCS616E
Image may vary slightly
See specifications for accurate information.
Reference: E2ZRN
Brand: Hager
Mfr. Part: MCS616E

Hager Quickbusbar C-Karacteristic 3P + N circuit breaker, tripping characteristic C, connecting neutral, nom. (measuring) current 16A, voltage type AC, 4 poles (total), width in module units 4, secondary device possible, connectable conductor cross-section duck 1 - 35mm², 3 protected poles.

View all
$135.14
excl VAT
In stock +3 days On request On request
0 are currently in your cart. For orders exceeding 0, expect an increased lead time of 3 days. Up to 11 items available for online order. For higher quantities, please contact us on support@tameson.com to request the lead time. The item is not available for online order, please contact us on support@tameson.com to request the lead time.
Shipping to United States: $14.95
Free for orders > $390.00
Expected delivery in 5 - 6 business days

Customers rate us: 4.98 / 5

506 reviews at TrustedShops

Description
Specifications
Downloads
Related products

Description

Hager Quickbusbar C-Karacteristic 3P + N circuit breaker, tripping characteristic C, connecting neutral, nom. (measuring) current 16A, voltage type AC, 4 poles (total), width in module units 4, secondary device possible, connectable conductor cross-section duck 1 - 35mm², 3 protected poles.

Downloads

Other Documentation (EN)
pdf
Download

Specifications

Built-in depth (mm)
70
Release characteristic
C
Number of poles (total)
4
Number of protected poles
3
Rated current (A)
16
Rated voltage (V)
400
Rated insulation voltage Ui (V)
500
Rated impulse withstand voltage Uimp (kV)
4
Voltage-type
AC
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V (kA)
6
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V (kA)
10
Frequency (Hz)
50 Hz to 60 Hz
Current limiting class
3
Flush-mounted installation
Yes
Concurrently switching neutral conductor
Yes
Over voltage category
3
Pollution degree
2
Additional equipment possible
Yes
Width in number of modular spacings
4
Degree of protection (IP)
The Ingress Protection (IP) rating indicating the product's resistance to dust and water, crucial for outdoor or harsh conditions.
IP20
Ambient temperature during operating (°C)
-25 °C to 70 °C
Connectable conductor cross section multi-wired (mm²)
1 mm² to 25 mm²
Connectable conductor cross section solid-core (mm²)
1 mm² to 35 mm²
Explosion-proof
No
