Image may vary slightly
See specifications for accurate information.
Reference: E28MN
Brand: Flexa steinheimer
Mfr. Part: 0233.201.016

Flexa steinheimer ROHRFLEX plastic ribbed cablebesch. Hose, polyamide 6, gray, nominal diameter 21.2mm, outer diameter 21.2mm, inner diameter 16.5mm, halogen-free, oil-resistant, degree of protection (IP) IP68, fire protection according to UL 94 V0, bending radius 45mm, bending radius, dynamic 75mm.

View all
$415.69
excl VAT
In stock +3 days On request On request
0 are currently in your cart. For orders exceeding 0, expect an increased lead time of 3 days. Up to 4 items available for online order. For higher quantities, please contact us on support@tameson.com to request the lead time. The item is not available for online order, please contact us on support@tameson.com to request the lead time.
Shipping to United States: Free
Free for orders > $390.00
Expected delivery in 5 - 6 business days

Customers rate us: 4.98 / 5

509 reviews at TrustedShops

Description
Specifications
Downloads

Description

Flexa steinheimer ROHRFLEX plastic ribbed cablebesch. Hose, polyamide 6, gray, nominal diameter 21.2mm, outer diameter 21.2mm, inner diameter 16.5mm, halogen-free, oil-resistant, degree of protection (IP) IP68, fire protection according to UL 94 V0, bending radius 45mm, bending radius, dynamic 75mm.

Downloads

Specifications

Nominal diameter (mm)
21.2
Outer-diameter (mm)
Outer diameter of the component.
21.2
Inner diameter (mm)
Inner diameter of the component.
16.5
Material
Choose a housing material that is not corroded by the media and environment, and can withstand the temperatures and pressures. Check out our chemical resistance chart.
Polyamide 6
Working temperature (°C)
-40 °C to 115 °C
Degree of protection (IP)
The Ingress Protection (IP) rating indicating the product's resistance to dust and water, crucial for outdoor or harsh conditions.
IP68
Fire resistance according to UL94
V0
Bending radius, static (mm)
45
Bending radius, dynamic (mm)
75
UV resistant
No
Oil resistant
Yes
Color
Grey
Sheathing material
Not sheathed
Flame accelerating
No
Bending strength
Flexible
Tensile strength (N)
0
Lengthwise slotted
No
Closable (two-part)
No
Halogen free
Yes
Approved according to DIN EN 61386-23
Yes
Approved according to UR
Yes
Approved according to CSA
Yes
Approved according to LUL/British Standard
Yes
Approved according to Lloyd's Register TA
Yes
Approved according to UTAC
No
Approved according to NF F 16-101
Yes
