Finder 20 Bistable Relay - 20.22.9.024.4000

Finder 20 Bistable Relay - 20.22.9.024.4000
Finder 20 Bistable Relay - 20.22.9.024.4000
Image may vary slightly
See specifications for accurate information.
Reference: E2F3S
Brand: Finder
Mfr. Part: 20.22.9.024.4000

Finder 20 bistable relay, (WxDxH) 17.5x55x60mm, coil voltage 1 21.6 - 26.4V, coil voltage type 1 DC, supply voltage 24V, DIN rail, 2 make contacts, coil voltage DC 24Vdc, nom. (measuring) switching current 16A, 1 module 18mm (TE), width in module units 1, frequency coil voltage 1 50 - 60Hz.

View all
$27.78 USD
excl VAT
In stock Ships in 2d On request On request
0 are currently in your cart. For orders exceeding 0, expect an increased lead time of 2 days. Up to 82 items available for online order. For higher quantities, please contact us on support@tameson.com to request the lead time. The item is not available for online order, please contact us on support@tameson.com to request the lead time.
Shipping to United States: $14.95 USD
Free for orders > $390.00 USD
Expected delivery in 4 - 5 business days

We sell only to registered businesses

Customers rate us: 4.95 / 5

552 reviews at TrustedShops

Description
Specifications
Downloads

Description

Finder 20 bistable relay, (WxDxH) 17.5x55x60mm, coil voltage 1 21.6 - 26.4V, coil voltage type 1 DC, supply voltage 24V, DIN rail, 2 make contacts, coil voltage DC 24Vdc, nom. (measuring) switching current 16A, 1 module 18mm (TE), width in module units 1, frequency coil voltage 1 50 - 60Hz.

Downloads

Compliance and Certification (EN)
pdf
Download
Compliance and Certification (EN)
pdf
Download
Compliance and Certification (EN)
pdf
Download
Compliance and Certification (EN)
pdf
Download

Specifications

Function
Mechanical switch
Mounting method
DIN raili
Width in number of modular spacings
1
Built-in depth
60.8 mm
Number of contacts as normally open contact
2
Number of contacts as normally closed contact
0
Number of contacts as change-over contact
0
Control voltage 1
21.6..26.4 V
Type of control voltage 1
DC
Frequency control voltage 1
50..60 Hz
Control voltage 2
0..0 V
Frequency control voltage 2
0..0 Hz
Rated switch current
16 A
Supply voltage
24..24 V
Voltage type of supply voltage
DC
Max. incandescent lamp load
2000 W
Max. load fluorescent lamp
1000 VA
Max. load fluorescent lamp (Duo circuit)
750 VA
Max. load fluorescent lamp (parallel compensated)
750 VA
Max. switching current (cos phi = 0.6)
18 A
