Finder 20 Bistable Relay - 20.21.9.024.4000

Finder 20 Bistable Relay - 20.21.9.024.4000
Finder 20 Bistable Relay - 20.21.9.024.4000
Image may vary slightly
See specifications for accurate information.
Reference: E2F3Q
Brand: Finder
Mfr. Part: 20.21.9.024.4000

Finder 20 bistable relay, (WxDxH) 17.5x55x60mm, coil voltage 1 21.6 - 26.4V, coil voltage type 1 DC, supply voltage 24V, DIN rail, 1 make contact, coil voltage DC 24Vdc, nom. (measuring) switching current 16A, 1 module 18mm (TE), width in module units 1, frequency coil voltage 1 50 - 60Hz.

View all
$21.05
excl VAT
In stock +40 days On request On request
0 are currently in your cart. For orders exceeding 0, expect an increased lead time of 40 days. Up to 100 items available for online order. For higher quantities, please contact us on support@tameson.com to request the lead time. The item is not available for online order, please contact us on support@tameson.com to request the lead time.
Shipping to United States: $14.95
Free for orders > $390.00
Expected delivery in 42 - 43 business days

Customers rate us: 4.98 / 5

509 reviews at TrustedShops

Description
Specifications
Downloads

Description

Finder 20 bistable relay, (WxDxH) 17.5x55x60mm, coil voltage 1 21.6 - 26.4V, coil voltage type 1 DC, supply voltage 24V, DIN rail, 1 make contact, coil voltage DC 24Vdc, nom. (measuring) switching current 16A, 1 module 18mm (TE), width in module units 1, frequency coil voltage 1 50 - 60Hz.

Downloads

Specifications

Function
Mechanical switch
Mounting method
DIN rail
Width in number of modular spacings
1
Built-in depth (mm)
60.8
Number of contacts as normally open contact
1
Number of contacts as normally closed contact
0
Number of contacts as change-over contact
0
Control voltage 1 (V)
21.6 V to 26.4 V
Type of control voltage 1
DC
Frequency control voltage 1 (Hz)
50 Hz to 60 Hz
Control voltage 2 (V)
0 V to 0 V
Frequency control voltage 2 (Hz)
0 Hz to 0 Hz
Rated switch current (A)
16
Supply voltage (V)
24 V to 24 V
Voltage type of supply voltage
DC
Max. incandescent lamp load (W)
2000
Max. load fluorescent lamp (VA)
1000
Max. load fluorescent lamp (Duo circuit) (VA)
750
Max. load fluorescent lamp (parallel compensated) (VA)
750
Max. switching current (cos phi = 0.6) (A)
18
Manual override
Yes
