Reference: P2F3F
Brand: Festo
Mfr. Part: HPV-22-60-A

The feed separator is a double-acting pneumatic cylinder designed for efficient material handling in automated systems. With a 22 mm piston diameter and 60 mm stroke, it delivers a theoretical force of 225 N at 6 bar when advancing. This compact unit features a non-rotating piston rod and integrated locking mechanism, making it suitable for precise positioning tasks. The cylinder's housing is compatible with SME/SMT-8 proximity sensors for enhanced control and monitoring capabilities.

View all
$1,047.79 USD
excl VAT
In stock Ships in 2d On request On request
0 are currently in your cart. For orders exceeding 0, expect an increased lead time of 2 days. Up to 1000 items available for online order. For higher quantities, please contact us on support@tameson.com to request the lead time. The item is not available for online order, please contact us on support@tameson.com to request the lead time.
Shipping to United States: Free
Expected delivery in 4 - 5 business days

We sell only to registered businesses

Customers rate us: 4.95 / 5

552 reviews at TrustedShops

Description
Specifications
Downloads

Description

The feed separator is a double-acting pneumatic cylinder designed for efficient material handling in automated systems. With a 22 mm piston diameter and 60 mm stroke, it delivers a theoretical force of 225 N at 6 bar when advancing. This compact unit features a non-rotating piston rod and integrated locking mechanism, making it suitable for precise positioning tasks. The cylinder's housing is compatible with SME/SMT-8 proximity sensors for enhanced control and monitoring capabilities.

Downloads

Product datasheet (EN)
pdf
Download
Brochure - HPV_ENUS
pdf
Download

Specifications

Piston diameter (mm)i
22
Stroke (mm)i
60
Operationi
Double acting
Pressure (bar)i
3 bar to 8 bar
Max force in (N)i
180
Max force out (N)i
225
Cylinder featurei
Reed switch,Square guide,Operation with oil lubrication possible (required in further operations)
Sensor mounting stylei
Double rod,Stop valve,Non-rotating rod
Connection sizei
M5
Connection typei
Inner thread metric
Temperature (°C)i
5 °C to 60 °C
Mounting method
Centering sleeve,With through-hole,With internal thread
Mounting dispositioni
Any
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
Note on materials
RoHS-compliant
Cycle time (ms)
796.1
External finger mounting
With through-hole
Half pulse (ms)
398.1
Max. interchangeability (mm)
0.3
