Festo Compact Cylinder 40mm Bore 15mm Stroke Single Acting - 157049
Notice: This product is discontinued
This compact air cylinder offers a space-efficient solution with a 40 mm piston diameter and 15 mm stroke. Operating in single-acting push mode, it delivers a theoretical force of 704 N at 6 bar. The cylinder features elastic cushioning rings at both ends for smooth operation and reduced wear. Its compact design requires 50% less installation space compared to ISO 15552 cylinders, making it ideal for applications with limited space. The magnetic piston allows for easy position sensing, enhancing control and monitoring capabilities.
Notice: This product is discontinued
Description
This compact air cylinder offers a space-efficient solution with a 40 mm piston diameter and 15 mm stroke. Operating in single-acting push mode, it delivers a theoretical force of 704 N at 6 bar. The cylinder features elastic cushioning rings at both ends for smooth operation and reduced wear. Its compact design requires 50% less installation space compared to ISO 15552 cylinders, making it ideal for applications with limited space. The magnetic piston allows for easy position sensing, enhancing control and monitoring capabilities.
