ESYLUX Compact Motion Switch (Complete) - EP10425783
Presence detector with 360° detection range for ceiling mounting. Range of up to 32 m, elliptical detection range of 32 m in length and 4 m in width, at a mounting height of 10 m (maximum mounting height approximately 15 m). Automatic light control (channel 1) at a constant brightness level (in a height up to 5 m) depending on presence and daylight (1 , 10 V = interface). Additional switching contact (channel 2) HVAC for switching an additional light source or for controlling heating/ventilation/air conditioning depending on presence.
- Regular price
- $174.74 USD
We sell only to registered businesses
Description
The presence detector with a 360° field of detection for ceiling mounting has a range of up to 32 meters. It has an elliptic detection range of 32 meters in length and 4 meters in width, at an installation height of 10 meters. The maximum installation height is approximately 10 meters. This device offers automatic light control depending on presence and daylight. It also has an additional HVAC switch contact for controlling heating, ventilation, and air conditioning depending on presence.
This detector is equipped with a 16 A high-performance relay, which is ideal for switching capacitive loads such as electronic ballasts, parallel-compensated fluorescent lamps, compact fluorescent lamps, and energy-saving lamps. The default settings ensure immediate operability. Programming is simplified using a remote control equipped with blue mode technology.
Interference sources can be masked by reducing sensitivity using DIP switches. This detector also features an additional switch input per channel. It can be used as a fully automatic or semi-automatic device. After the time setting expires, the luminous efficiency lowers to 10% to serve as an orientation light for hallways and passageways.
The detector comes with an in-built switch-off warning. It is a flush-mounted device as standard. It can be surface mounted or recessed ceiling mounted with accessories. The cover and design ring are easily replaceable and paintable. The field of detection can be extended by connecting slave devices. Areas can be targeted for masking out by means of an enclosed lens mask.
