Eaton Undervoltage Release Coil 400V Non-Delayed 1HP - 248290
The Eaton Industries Xpole auxiliary device is a modular undervoltage release screwable unit with a rated operating voltage of 400V AC. It possesses a non-delayed function and operates at a frequency of 50-60hz. The closing and tripping thresholds are 80% and below 30% of Un respectively. The unit has a standard front dimension of 45 mm and a mounting width of 1 MU (17.5mm). The Din-rail mounting offers easy installation and the terminal cross-section can accommodate 1-2x2.5 mm².
- Regular price
- $125.61 USD
We sell only to registered businesses
Description
The Eaton Industries Xpole auxiliary device is a modular undervoltage release screwable unit with a rated operating voltage of 400V AC. It possesses a non-delayed function and operates at a frequency of 50-60hz. The closing and tripping thresholds are 80% and below 30% of Un respectively. The unit has a standard front dimension of 45 mm and a mounting width of 1 MU (17.5mm). The Din-rail mounting offers easy installation and the terminal cross-section can accommodate 1-2x2.5 mm².
