Eaton Terminal Plate 3P 6-50mm2 54mm BBA-TP3/50 - 107183
The Eaton Industries XEffect connection terminal has a width of 54mm and is suitable for rail thicknesses from 5mm to 10mm and widths from 12mm to 30mm. It is compatible with band, round, and sector conductors, with a maximum conductor cross-section of 50mm². It has a maximum nominal operational current (Ie) of 300A. The terminal, compliant with a 60mm system with screw terminals, has a terminal capacity of 6 up to 50mm² or AWG10-AWG2 or 6x9x0.8. It is also silicon and chlorine-free, self-extinguishing to UL 94, and temperature resistant up to 120 °C. Its termination space measures 15x10mm and can be removed for the connection of uncut conductors. However, passing through the terminal is not possible.
- Regular price
- $46.33 USD
We sell only to registered businesses
Description
The Eaton Industries XEffect connection terminal has a width of 54mm and is suitable for rail thicknesses from 5mm to 10mm and widths from 12mm to 30mm. It is compatible with band, round, and sector conductors, with a maximum conductor cross-section of 50mm². It has a maximum nominal operational current (Ie) of 300A. The terminal, compliant with a 60mm system with screw terminals, has a terminal capacity of 6 up to 50mm² or AWG10-AWG2 or 6x9x0.8. It is also silicon and chlorine-free, self-extinguishing to UL 94, and temperature resistant up to 120 °C. Its termination space measures 15x10mm and can be removed for the connection of uncut conductors. However, passing through the terminal is not possible.
