Eaton Sign Lamp Red LED 24V AC/DC Single Light Z-BEL/R24 - 284931
This Eaton Industries device is a modular optical signal generator with an optional acoustic feature. It displays a red signal with a nominal operating voltage of 24V AC/DC and a maximum power loss of 2W. The switching frequency is 2kHz, with a mounting depth of 60mm and an IP40 protection degree. The device, which adheres to the optical signal type, is fitted with a screw and measures one module in size, suitable for DIN-rail assembly. It includes a single lamp with a built-in flash function, boasting an LED color of red, a luminosity of 15mcd, and a heat dissipation of 2W/LED. Its flashing frequency is typically 2 Hz, with a front size of 45 mm, and is mounted on a top-hat rail. Furthermore, it has a terminal cross-section of 1-10 mm², and meets IEC/EN 60669, VDE 0632 standards.
- Regular price
- $34.23 USD
We sell only to registered businesses
Description
This Eaton Industries device is a modular optical signal generator with an optional acoustic feature. It displays a red signal with a nominal operating voltage of 24V AC/DC and a maximum power loss of 2W. The switching frequency is 2kHz, with a mounting depth of 60mm and an IP40 protection degree. The device, which adheres to the optical signal type, is fitted with a screw and measures one module in size, suitable for DIN-rail assembly. It includes a single lamp with a built-in flash function, boasting an LED color of red, a luminosity of 15mcd, and a heat dissipation of 2W/LED. Its flashing frequency is typically 2 Hz, with a front size of 45 mm, and is mounted on a top-hat rail. Furthermore, it has a terminal cross-section of 1-10 mm², and meets IEC/EN 60669, VDE 0632 standards.
