Eaton Lightning Current Arrester Type 1 260VAC 100KA SPI-100/NPE - 263139

Notice: This product is discontinued

Discontinued
Eaton Lightning Current Arrester Type 1 260VAC 100KA SPI-100/NPE - 263139
Eaton Lightning Current Arrester Type 1 260VAC 100KA SPI-100/NPE - 263139
Image may vary slightly
See specifications for accurate information.
Reference: E3DTQ
Brand: EATON INDUSTRIES
Mfr. Part: 263139

The Eaton Industries Xpole is a lightning current arrester, specifically designed to protect consumer systems. Its application is in accordance with IEC60364-5-53 clause 534, which sets the safety standard for low-voltage electrical installations with a focus on overvoltage protection. This device prevents damage or disruptions from lightning strikes and associated power surges, essential for the protection of sensitive electrical systems.

View all
Note: product cannot be returned

Notice: This product is discontinued

Description
Specifications
Downloads

Description

The Eaton Industries Xpole is a lightning current arrester, specifically designed to protect consumer systems. Its application is in accordance with IEC60364-5-53 clause 534, which sets the safety standard for low-voltage electrical installations with a focus on overvoltage protection. This device prevents damage or disruptions from lightning strikes and associated power surges, essential for the protection of sensitive electrical systems.

Downloads

Specifications

System configuration DC
No
System configuration IT
No
System configuration TN
No
System configuration TN-C
No
System configuration TN-C-S
No
System configuration TN-S
No
System configuration TT
No
System configuration other
No
Lightning impulse current (10/350 µs) (kA)
100
Nominal discharge surge current (8/20) (kA)
100
Max. continuous voltage AC (V)
260
Max. continuous voltage DC (V)
0
Nominal voltage AC (V)
0
Nominal voltage DC (V)
0
Voltage protection level (kV)
1.5
Voltage protection level L-N (kV)
0
Voltage protection level N-PE (kV)
0
Voltage protection level (DC+ - DC-) (kV)
0
Voltage protection level (DC+/DC- - PE) (kV)
0
Follow current extinguishing capability (kA)
0
Specific energy (W/R) (kJ/Ohm)
0
Mounting method
DIN rail (top hat rail) 35 mm
Construction size
2 modular spacing
Max. conductor cross section solid (solid, stranded) (mm²)
50
Max. conductor cross section flexible (fine-strand) (mm²)
35
With remote signalling contact
No
Exhausting
No
Signalling at the device
Optic
Category type 1
Yes
Integrated backup fuse
No
Suitable for outdoor use
No
