Eaton Installation Contactor 230VAC 50Hz 63A 4NO 3HP - 248856
The Eaton Industries Installation Contactor is a modular device with a rated operational current of 63A and a rated control circuit voltage of 230V AC. It functions with 4 N/O and its performance meets the standards of IEC 61095, EN 61095, VDE 0660, IEC 60947-4-1_x, EN 60947-4-1, and VDE. The device is designed with a standard front dimension of 45mm and a mounting width of 3 SU (52.5mm), suitable for top-hat rail mounting. It operates at an operating (measuring) voltage of 440V and an energizing (supply) voltage ranging from 195.5 - 253V. It has four making contacts and a maximum incandescent lamp load of 7740W.
- Regular price
- $135.14 USD
We sell only to registered businesses
Description
The Eaton Industries Installation Contactor is a modular device with a rated operational current of 63A and a rated control circuit voltage of 230V AC. It functions with 4 N/O and its performance meets the standards of IEC 61095, EN 61095, VDE 0660, IEC 60947-4-1_x, EN 60947-4-1, and VDE. The device is designed with a standard front dimension of 45mm and a mounting width of 3 SU (52.5mm), suitable for top-hat rail mounting. It operates at an operating (measuring) voltage of 440V and an energizing (supply) voltage ranging from 195.5 - 253V. It has four making contacts and a maximum incandescent lamp load of 7740W.
