Eaton Installation Contactor 230VAC 50Hz 2NO 2NC 40A 3HP - 248853
The Eaton Industries Installation Contactor is a modulated device with a rated control circuit voltage of 230V AC, and an operational current at AC1 of 40A. It's equipped with features like 2 normally open (N/O) and 2 normally closed (N/C) contacts. It follows the guidelines of IEC 61095, EN 61095, VDE 0660, IEC 60947-4-1_x, EN 60947-4-1, and VDE standards. With standard front dimensions of 45mm and a mounting width of 3 SU (52.5mm), it can be easily fitted onto a top-hat rail. The operational measuring voltage is 440V, while the actuation voltage ranges between 195.5 - 253V.
- Regular price
- $116.54 USD
We sell only to registered businesses
Description
The Eaton Industries Installation Contactor is a modulated device with a rated control circuit voltage of 230V AC, and an operational current at AC1 of 40A. It's equipped with features like 2 normally open (N/O) and 2 normally closed (N/C) contacts. It follows the guidelines of IEC 61095, EN 61095, VDE 0660, IEC 60947-4-1_x, EN 60947-4-1, and VDE standards. With standard front dimensions of 45mm and a mounting width of 3 SU (52.5mm), it can be easily fitted onto a top-hat rail. The operational measuring voltage is 440V, while the actuation voltage ranges between 195.5 - 253V.
