Eaton Circuit Breaker 3P 40A Motor Protection NZMH1-M40 - 115450
Notice: This product will be discontinued in the future
The Eaton Industries MCCB motor protection circuit breaker has dimensions of 90x88x145mm, an overload setting range of 32-40A, and a nominal continuous current Iu of 40A. The device shape allows for built-in installation with a fixed location. Connection method for the main current circuit is classified as "other". The tripping technology is thermo-magnetic with an IP20 degree of protection. The NZM series circuit breakers come in four compact sizes, providing flexibility for all applications in the IEC market. Features phase-failure sensitivity, a tripping class of 10A, and meets all the requirements of the switching category AC-3 according to IEC/EN 60947-4-1 and IEC/EN 60947-2.
Notice: This product will be discontinued in the future
Description
The Eaton Industries MCCB motor protection circuit breaker has dimensions of 90x88x145mm, an overload setting range of 32-40A, and a nominal continuous current Iu of 40A. The device shape allows for built-in installation with a fixed location. Connection method for the main current circuit is classified as "other". The tripping technology is thermo-magnetic with an IP20 degree of protection. The NZM series circuit breakers come in four compact sizes, providing flexibility for all applications in the IEC market. Features phase-failure sensitivity, a tripping class of 10A, and meets all the requirements of the switching category AC-3 according to IEC/EN 60947-4-1 and IEC/EN 60947-2.
