Eaton 4P Terminal Plate With Copper Band Up To 32x20mm 800A - 138386
This is an Eaton Industries XEffect connection kit with a 60mm system and 4 poles. The terminal capacity supports up to 10x32x1, 30x25, with a maximum nominal operating current of 800A. The kit is suitable for a busbar with a thickness of 5 - 10mm and width of 20 - 30mm. The terminal clamp width ranges between 180 - 228mm and can be used for rail sizes of 20x5/10, 25x5/10, 30x5/10 and double T profiles. The kit includes a shroud with adjustable width and fixing is performed directly over the busbar terminals. A through-connection is not permitted. It is silicon-free, chlorine-free, self-extinguishing to UL 94, with a Comparative Tracking Index of 200, and is temperature resistant up to 120 °C.
- Regular price
- $260.36 USD
We sell only to registered businesses
Description
This is an Eaton Industries XEffect connection kit with a 60mm system and 4 poles. The terminal capacity supports up to 10x32x1, 30x25, with a maximum nominal operating current of 800A. The kit is suitable for a busbar with a thickness of 5 - 10mm and width of 20 - 30mm. The terminal clamp width ranges between 180 - 228mm and can be used for rail sizes of 20x5/10, 25x5/10, 30x5/10 and double T profiles. The kit includes a shroud with adjustable width and fixing is performed directly over the busbar terminals. A through-connection is not permitted. It is silicon-free, chlorine-free, self-extinguishing to UL 94, with a Comparative Tracking Index of 200, and is temperature resistant up to 120 °C.
