Eaton 12A Circuit Breaker 3P 50KA UL/IEC NZMN1-S12-CNA - 103030
The Eaton Industries MCCB motor protection switch is a compact device with dimensions of 90x88x165.5mm. It is a built-in device with a nominal continuous current Iu of 12A. The switch uses magnetic tripping mechanism and it connects via the main circuit. It has an IP20 degree of protection. Its operating voltage is 690V. The NZM..-S..CNA circuit-breakers are compatible worldwide and are offered in four compact sizes. They feature modular function groups for flexible mounting. These circuit-breakers use magnetic short-circuit release in conjunction with an overload relay, and come with a short-circuit release lacking overload trip. The devices conform to UL/CSA as well as IEC regulations as mentioned on the rating plate.
- Regular price
- $558.10 USD
We sell only to registered businesses
Description
The Eaton Industries MCCB motor protection switch is a compact device with dimensions of 90x88x165.5mm. It is a built-in device with a nominal continuous current Iu of 12A. The switch uses magnetic tripping mechanism and it connects via the main circuit. It has an IP20 degree of protection. Its operating voltage is 690V. The NZM..-S..CNA circuit-breakers are compatible worldwide and are offered in four compact sizes. They feature modular function groups for flexible mounting. These circuit-breakers use magnetic short-circuit release in conjunction with an overload relay, and come with a short-circuit release lacking overload trip. The devices conform to UL/CSA as well as IEC regulations as mentioned on the rating plate.
