DEHNbloc Maxi Lightning Current Arrester Type 1 DBM 1 440 V AC - 961140
The DEHNbloc Maxi is a coordinated single-pole lightning current arrester that uses RADAX Flow technology for high follow current extinction and limitation. It is designed for the protection of low voltage consumer’s installations against surges and direct lightning strikes. It is type 1 according to EN 61643-11 standard and should be installed per the lightning protection zone's parameters from 0A – 1. The arrester possesses a maximum flexible conductor cross section of 35mm², comprises one conductor excluding earth, and has a protection degree of IP20. This device also supports a maximum solid conductor cross section of 50mm², a maximum continuous AC voltage of 440V, and can be mounted on a 35mm DIN-rail. Suitable for IT, TN, and TN-C network forms.
- Regular price
- $414.95
Description
The DEHNbloc Maxi is a coordinated single-pole lightning current arrester that uses RADAX Flow technology for high follow current extinction and limitation. It is designed for the protection of low voltage consumer’s installations against surges and direct lightning strikes. It is type 1 according to EN 61643-11 standard and should be installed per the lightning protection zone's parameters from 0A – 1. The arrester possesses a maximum flexible conductor cross section of 35mm², comprises one conductor excluding earth, and has a protection degree of IP20. This device also supports a maximum solid conductor cross section of 50mm², a maximum continuous AC voltage of 440V, and can be mounted on a 35mm DIN-rail. Suitable for IT, TN, and TN-C network forms.
