Dehnbloc M 1 150 FM Lightning Current Arrester - 961115

Dehnbloc M 1 150 FM Lightning Current Arrester - 961115
Dehnbloc M 1 150 FM Lightning Current Arrester - 961115
Dehnbloc M 1 150 FM Lightning Current Arrester - 961115
Image may vary slightly
See specifications for accurate information.
Reference: E3JAB
Brand: DEHN
Mfr. Part: 961115

The DEHNbloc modular lightning current arrester is a single-pole, spark-gap-based type 1 device according to EN 61643-11. It comprises a base part and a plug-in protection module. With RADAX Flow follow current limitation, it ensures maximum system availability. It can protect low-voltage consumer installations against surges and even direct lightning strikes. It can be installed in accordance with the lightning protection zone concept at the boundaries from 0A – 1. The device supports a max continuous AC voltage of 150V and has a DIN rail of 35mm. It uses max conductor cross-section flexible 35mm² and rigid 50mm² (excluding earth). It has a level of protection (IP) of IP20 and a DIN size of 2 TE (Grid size). This surge protector is compatible with TN and TN-C network type. It also includes a status contact.

View all
Note: product cannot be returned
Regular price
$332.98
excl VAT

In stock +11 days On request On request
0 are currently in your cart. For orders exceeding 0, expect an increased lead time of 11 days. Up to 8 items available for online order. For higher quantities, please contact us on support@tameson.com to request the lead time. The item is not available for online order, please contact us on support@tameson.com to request the lead time.


Shipping to United States: $14.95
Free for orders > $390.00
Expected delivery in 13 - 14 business days

Description
Specifications
Downloads

The DEHNbloc modular lightning current arrester is a single-pole, spark-gap-based type 1 device according to EN 61643-11. It comprises a base part and a plug-in protection module. With RADAX Flow follow current limitation, it ensures maximum system availability. It can protect low-voltage consumer installations against surges and even direct lightning strikes. It can be installed in accordance with the lightning protection zone concept at the boundaries from 0A – 1. The device supports a max continuous AC voltage of 150V and has a DIN rail of 35mm. It uses max conductor cross-section flexible 35mm² and rigid 50mm² (excluding earth). It has a level of protection (IP) of IP20 and a DIN size of 2 TE (Grid size). This surge protector is compatible with TN and TN-C network type. It also includes a status contact.
