Dehn Earthing Pipe Clamp D 21mm With Connection Clamp Rd 4-10mm - 407012
The Earthing pipe clamp lightning protection, made of malleable cast iron, has a clamping range of 21mm with a maximum and minimum clamping range of 1/2" as per EN 62561-1 standards. It integrates pipes into the protective and functional equipotential bonding in accordance with IEC standards 60364-4-41/60364-5-54 (DIN VDE 0100-410/540) and lightning equipotential bonding according to IEC 62305-3 standard. This pipe clamp, with an M10 screw, accommodates a conductor cross-section of 4-70 mm². It has a single conductor and features a galvanized surface for thermal protection.
- Regular price
- $32.40 USD
We sell only to registered businesses
Description
The Earthing pipe clamp lightning protection, made of malleable cast iron, has a clamping range of 21mm with a maximum and minimum clamping range of 1/2" as per EN 62561-1 standards. It integrates pipes into the protective and functional equipotential bonding in accordance with IEC standards 60364-4-41/60364-5-54 (DIN VDE 0100-410/540) and lightning equipotential bonding according to IEC 62305-3 standard. This pipe clamp, with an M10 screw, accommodates a conductor cross-section of 4-70 mm². It has a single conductor and features a galvanized surface for thermal protection.
