Dehn Earth Rod Connector For 20-30mm Rd 8-12.5mm Fl-40mm Cables - 610010
This is a Dehn connection clamp made of steel and designed for depth grounding. It adheres to EN 62561-1 standards and is used for the cross and parallel connection of round conductors, flat strips, or cables to earth rods. The clamp is designed for earth rods with a diameter ranging between 20-30mm and it comes equipped with four M10 screws. The clamp range for round conductors is 8-12.5mm, for flat conductors up to 40mm, and for cables between 50-95mm². The entire clamp is protected with a thermally galvanized surface for enhanced durability.
- Regular price
- $43.97 USD
Description
This is a Dehn connection clamp made of steel and designed for depth grounding. It adheres to EN 62561-1 standards and is used for the cross and parallel connection of round conductors, flat strips, or cables to earth rods. The clamp is designed for earth rods with a diameter ranging between 20-30mm and it comes equipped with four M10 screws. The clamp range for round conductors is 8-12.5mm, for flat conductors up to 40mm, and for cables between 50-95mm². The entire clamp is protected with a thermally galvanized surface for enhanced durability.
