Belimo Ball Valve G3/4 Kvs4 R410DK
This is a Belimo 2-way ball valve with a brass housing and EPDM sealing. The ball within the valve is made of stainless steel. The bore diameter of the valve is DN 10 and the port size is G 3/4 inch with male threads. The maximum pressure differential is 8 bar (116 psi). The valve can operate between 2 and 130 °C (36 and 266 °F). The Kv value of the valve is 4 m3/h, equivalent to a Cv-value of 5 gpm. This valve requires a separate Belimo open/close actuator, which is not included. Installing Belimo actuators on this valve is made easy due to the central bolt design.
- Regular price
- $178.77 USD
We sell only to registered businesses
Description
This is a Belimo 2-way ball valve with a brass housing and EPDM sealing. The ball within the valve is made of stainless steel. The bore diameter of the valve is DN 10 and the port size is G 3/4 inch with male threads. The maximum pressure differential is 8 bar (116 psi). The valve can operate between 2 and 130 °C (36 and 266 °F). The Kv value of the valve is 4 m3/h, equivalent to a Cv-value of 5 gpm. This valve requires a separate Belimo open/close actuator, which is not included. Installing Belimo actuators on this valve is made easy due to the central bolt design.
Pros:
- Very easy installation of Belimo actuators with the central bolt
- Designed for open/close operation
Series:
The Belimo R2-S series is designed for open and closed cold and warm water systems. With the ability to operate in air-handling units and heating systems, the series offers shut-off functions on the water side and 2-point controls. One key feature is its air-bubble tight capability, ensuring efficient operations. The series accommodates a range of applications, suitable for sizes ranging from DN15-50. This makes it a versatile choice for different settings. This series is a reflection of Belimo's commitment to providing reliable and efficient solutions.
