Image may vary slightly
See specifications for accurate information.
Reference: V2PSV
Brand: Airtec
Mfr. Part: P-05-520

Use a 5/2-way valve in applications that move continuously between two positions, such as extending and retracting double-acting cylinders, where it is not necessary to stop air pressure.

View all
$68.15 USD
excl VAT
In stock Ships in 2d On request On request
0 are currently in your cart. For orders exceeding 0, expect an increased lead time of 2 days. Up to 28 items available for online order. For higher quantities, please contact us on support@tameson.com to request the lead time. The item is not available for online order, please contact us on support@tameson.com to request the lead time.
Shipping to United States: $14.95 USD
Free for orders > $390.00 USD
Expected delivery in 4 - 5 business days

We sell only to registered businesses

Customers rate us: 4.95 / 5

552 reviews at TrustedShops

Description
Specifications
Downloads

Description

Use a 5/2-way valve in applications that move continuously between two positions, such as extending and retracting double-acting cylinders, where it is not necessary to stop air pressure.

Downloads

Airtec P05
pdf
Download

Specifications

Connection sizei
1/8 inch
Connection type
Inner thread cylindrical BSPP-G
Functioni
Bistable
Materiali
Aluminium
Seal materiali
NBR (nitrile rubber)
Valve ports/positionsi
5/2 way
Max pressure (bar)i
10
Valve bore (mm)
6
Kv value [m3/h] (m³/h)i
0.67
Min temperature (°C)i
-10
Max temperature (°C)i
70
Max control pressure (bar)
10
Min control pressure (bar)
2
Max flow rate (l/min)
750
Model
Airtec P-05
Surface protection
Anodized
Max pressure (bar)
10
Actuationi
Air
