Festo Cylinder 40mm Bore 200mm Stroke ISO 15552 Double Acting - 1376663
This ISO 15552-compliant double-acting cylinder features a 40 mm piston diameter and 200 mm stroke, delivering a theoretical force of 754 N at 6 bar when advancing. It includes adjustable pneumatic cushioning at both ends for optimal performance under varying loads and speeds. The standard profile design incorporates two sensor slots and a magnetic piston for position sensing, while offering versatile mounting options to suit diverse installation requirements.
- Regular price
- $193.48 USD
We sell only to registered businesses
Description
This ISO 15552-compliant double-acting cylinder features a 40 mm piston diameter and 200 mm stroke, delivering a theoretical force of 754 N at 6 bar when advancing. It includes adjustable pneumatic cushioning at both ends for optimal performance under varying loads and speeds. The standard profile design incorporates two sensor slots and a magnetic piston for position sensing, while offering versatile mounting options to suit diverse installation requirements.
